Geehy – APM32F103C8T6: 32-bit microcontroller with ARM® Cortex®-M3 core

The APM32F103C8T6 delivers fast and reliable processing capabilities for real-time applications such as motor control, industrial equipment, and smart consumer products. Users are equipped with a powerful core to handle complex tasks, featuring 64 KB Flash and 20 KB SRAM, making the microcontroller fully capable of mid-range embedded systems without the need for external memory.

Additionally, its intelligent memory architecture accelerates response times and optimizes data flow in systems requiring high stability, with three power-saving modes: Sleep, Stop, and Standby. These modes help extend battery life for handheld devices or systems running 24/7 without excessive power consumption.

The APM32F103C8T6 offers diverse connectivity interfaces and precise control with powerful timers, PWM, RTC, watchdog, and more. It supports CRC, a unique 96-bit device ID, and flexible debug interfaces (JTAG, SWD), ensuring device security and uniqueness.

Specifications:

– Processor core: ARM Cortex-M3, maximum frequency 96 MHz.

– Memory: 64 KB Flash, 20 KB SRAM.

– Power supply: 2.0V to 3.6V, 1.8V to 3.6V (supports RTC and backup register).

– Peripheral interface: USART, SPI, I²C, CAN, USB, ADC, RTC, I/O,….

– Debug interface: Supports both JTAG and SWD

– Security features: 96-bit Unique ID cannot be overwritten, supports CRC.

– Package: LQFP-48 (7×7 mm)

Advantages:

– Superior performance – Elevate every application

– Ideal memory – Flexible storage, instant response

– Energy saving – Durable over time

– Diverse communication – Unlimited connectivity

– Precise control

– Safe and reliable

Applications:

– Industrial and automation equipment.

– Consumer electronics.

– Motor control systems.

– Portable medical devices.

– Embedded systems in automobiles.

Learn more: APM32F103C8T6
