Navita - NV6128C : V6128C 650 V GaNFast™ IC Power

The NV6128C integrates FET, control, and logic in a single chip, simplifying design and improving efficiency. The product operates at high frequencies of up to 2 MHz and can withstand continuous voltages up to 650 V and surge voltages up to 800 V. The NV6128C helps save up to 40% energy compared to traditional silicon solutions.

Additionally, its compact size and ability to minimize inductance are advantageous, optimizing space and thermal performance. The product is suitable for various applications such as mobile fast chargers, AC-DC converters, DC-DC converters, LED lighting, and many other applications.

Specifications:

– Continuous Voltage Drain-to-Source (VDSDS): 650 V

– Pulse Voltage Drain-to-Source (VDSDS): 800 V

– Continuous Current Drain (IDD) at junction temperature 100°C: 16 A

– Impulse Drain (IDD) current for 10 μs at junction temperature 25°C: 32 A

– ESD protection (HBM): 2 kV

– ESD protection (CDM): 1 kV

– Supply voltage (VCCCC): 10 – 30 V

– Voltage supplied to the driver (VDDDD): 7.5 V

Advantages:

– Integrates FET, control and logic in one chip

– High voltage resistance

– Good heat resistance

– ESD protection

– Save energy

Applications:

– Portable fast charger, AC-DC, DC-DC converter

– LED light, and many other applications.

Learn more: NV6128C

Contact EPI Vietnam Technologies – the authorized distributor of Navitas in Vietnam for better support on products and prices
